| Line-of-sight Detection Distance: | 10km (typical Case) | Distance Resolution: | 30m/45m/60m/75m Optional |
|---|---|---|---|
| Accumulation Time: | 0.5s/1s/2s/4s/8s Optional | Radial Wind Speed Measurement Range: | -75~+75 M/s |
| Radial Wind Speed Measurement Accuracy: | 0.1m/s | Horizontal Scan Range: | 360° × N |
| Scanning Method: | PPI , RHI , DBS , LOS And Program Scan | ||
| Highlight: | 100% RH Humidity Offshore Wind Lidar,5% RH Humidity Offshore Wind Lidar,Non Condensing Lidar Wind Measurement |
||
Operating ambient humidity 5%~100% RH non-condensing
1,Application Case: Fan Wake Measurement
When a fan extracts energy from the wind, a wake is created downwind of the fan, which is essentially a turbulent flow. The wake of the wind turbine is characterized by the decrease of wind speed and the increase of turbulence at the downwind of the wind turbine. Especially in large wind farms, the wake effect is more obvious.
2,Performance parameters
| Basic parameters | |
| Line-of-sight detection distance | 10km (typical case) |
| Distance resolution | 30m/45m/60m/75m optional |
| Accumulation time | 0.5s/1s/2s/4s/8s optional |
| Radial wind speed measurement range | -75~+75 m/s |
| Radial wind speed measurement accuracy | 0.1m/s |
| Number of distance layers | up to 300 |
| Horizontal scan range | 360° × n |
| Vertical scan range | -10°~190° |
| Pointing accuracy | 0.1° |
| Scanning method | PPI , RHI , DBS , LOS and Program Scan |
| Real-time data output form | Profibus DP/Modbus TCP/CAN optional |
| Telecommunication | 1000BASE-TX or 4G remote access |
| Environmental parameters | |
| Operating temperature and humidity | -25~+50℃ (extendable to -40~+60℃), 5%~100% RH |
| IP protection class | Housing IP54, core module IP66 |
| Anticorrosion grade | C4 |
| Survival wind speed | 70m/s (fixed by foot or by wire rope) |
| Working altitude | ≤3500m |
| Other parameters | |
| Running power consumption | ≤1kW |
| Powered by | 110VAC±20% or 220VAC±20%, 50Hz±10% |
| Size | 800mm*650mm*11 30mm |
| Weight | ≤150kg |
| Accessibility | |
| GNSS functionality | Support GPS/Beidou |
| Time service | NTP timing or GPS/Beidou timing |
3,Schematic diagram of 3D scanning Doppler wind Lidar
